Hawkeye -- a weapon for 360° large scene monitoring

With the deepening of video surveillance applications, we have more and more surveillance needs for large scenes, such as large squares, stadiums, meeting places, airports, stations, wharfs, etc. In addition to the requirements of “seeing the whole” and “real-time”, we also hope to clearly see the local details. Although the needs of “seeing the whole” and “real-time” can be met by more and more integrated high-definition panoramic cameras or through the stitched programs by the rears of multiple cameras, both can not see the local details of the large scene in a thorough manner. If a sudden event occurs in a large scene, we want to see the details, and clearly record the entire process of the incident; otherwise, although with non-blind spot panoramic surveillance advantages, we can not distinguish the monitored objects and details, and the surveillance at this time becomes useless. Therefore, for large scenes, we not only want to look around, but also can capture details.

Completely solve the contradictions where whole scenes and details can not be obtained simultaneously

  • Product features
  • Technical parameters
  • Color 0.001Lux star-level ultra-low illumination, panoramic fixed-focus supports 5mm focal length, and close-up ball machine supports 37 times optical zoom
  • Support the detection of moving targets within the range of 300 meters in diameter, able to simultaneously detect 60 targets
  • Multiple linkages: click linkage, intelligent linkage, and manual tracking
  • Server-free: the product has integrated designs, with no server support required
  • One optical port and one electrical port
  • Support multi-target tracking
  • Target switching time is less than 1 second
  • Calibration method: automatic / manual
  • Intelligent event detection: regional intrusion, cross-border, enter the region, and leave the region
  • Sensor type: 1/1.9” Progressive Scan CMOS
  • Color: 0.002 Lux @ (F2.2, AGC ON);
  • Black and white: 0.0002Lux @ (F2.2, AGC ON)
  • Lens: f5.0mm / F2.2
  • Video compression: H.264 (Baseline/Main/High Profile)
  • Image sensor: 1/1.9” Progressive Scan CMOS
  • Focal length: 5.6-208mm, and 37 times optical zoom
  • F-number: F1.5-F4.5
  • Operating temperature and humidity: -40°C-65°C; the humidity is less than 90% RH
